Critical ionization velocity

Critical ionization velocity (CIV, also called Critical velocity, CV) is the relative velocity between a neutral gas and plasma (an ionized gas), at which the neutral gas will start to ionize. If more energy is supplied, the velocity of the atoms or molecules will not exceed the critical ionization velocity until the gas becomes almost fully ionized.

The phenomenon was predicted by Swedish engineer and plasma scientist, Hannes Alfvén, in connection with his model on the origin of the Solar System (1942)[1][2][3]. At the time, no known mechanism was available to explain the phenomenon, but the theory was subsequently demonstrated in the laboratory,[4]. Subsequent research by Brenning and Axnäs (1988)[5] have suggested that a lower hybrid plasma instability is involved in transferring energy from the larger ions to electrons so that they have sufficient energy to ionize. Application of the theory to astronomy though a number of experiments have produced mixed results [6] [7].

The phenomenon is also called the Critical velocity ionization,[8], and also Critical velocity effect,[9].

Experimental research

The Royal Institute of Technology in Stockholm carried out the first laboratory tests, and found that (a) the relative velocity between a plasma and neutral gas could be increased to the critical velocity, but then additional energy put into the system then went into ionizing the neutral gas, rather than into
increasing the relative velocity, (b) the critical velocity is roughly independent of the pressure and magnetic field. [10].

In 1970, the Apollo XIII mission provided indirect evidence of the critical velocity phenomenon:

“The fact that the critical velocity phenomenon occurs even in space plasma was discovered by an accident in the context of the Apollo program. When Apollo XIII had to return to Earth prematurely after an accident, the carrier rocket continued toward the Moon. When it hit the lunar surface with great force, dust and gas clouds were formed, which expanded out into the solar wind. Instruments left on the lunar surface by Apollo XII then showed a strongly enhanced flux of energetic ions. These were ions which were formed from the neutral gas cloud and subsequently accelerated in the electric field of the solar wind. The acceleration was expected, but what was surprising was that such a large part of the neutral gas cloud had become ionized. Analysis showed that the only explanation appeared to be the critical velocity phenomenon. (The solar wind velocity, 300 — 900 km/s, exceeds greatly the critical velocity for all ion species concerned.)”[11][12]

In 1973, Lars Danielsson published a review of critical ionization velocity, and concluded that the existence of the phenomenon “is proved by sufficient experimental evidence”[13]. In 1976, Alfvén reported that “The first observation of the critical velocity effect under cosmic conditions was reported by Manka et al. (1972)[14] from the Moon. When an abandoned lunar [391] excursion module was made to impact on the dark side of the Moon not very far from the terminator, a gas cloud was produced which when it had expanded so that it was hit by the solar wind gave rise to superthermal electrons.”[15]

In the laboratory, critical ionization velocity has been recognised for some time, and is seen in the penumbra produced by a dense plasma focus device (or plasma gun). Its existence in cosmic plasmas has not been confirmed.

In 1986, Gerhard Haerendel, suggested that critical velocity ionization may stabilize the plasma flow in a cometary coma,[16]. In 1992, E. Golbraikh and M. Filippov argued that critical ionization velocity could play a role in coronal mass ejections and solar flares [17], and in 1992, Anthony Peratt and Gerrit Verschuur suggested that interstellar neutral hydrogen emissions bore the signature of critical velocity ionization,[18].

A 2001 review of the phenomenon by Shu T. Lai reports that “.. laboratory experiments, and computer simulations have all shown CIV as feasible and reasonably understood, although all CIV experiments in space have yielded negative results with perhaps three exceptions”[19]. Also in 2001, C. Konz, et al, “.. discuss the critical velocity effect as a possible explanation for the observed Hα emission [..] in the Galactic halo near the edges of cold gas clouds of the Magellanic Stream”[20]

In 2007, radio astronomer Gerrit Verschuur reported a study “which strongly suggests the existence of a mechanism in interstellar space in which the CIV effect influences the motion of neutral hydrogen atoms.”[21]. And and investigation by physicist Valentin A. Rantsev-Kartinov on whether planets are located on dusty filaments, concluded that:

“The data presented show that the structure of cosmic dust clouds has a skeletal or concentric cylindrical filamental structure similar to the skeletal found in carbonaceous dust particles in the dusty plasma associated with laboratory discharge experiments. The consequences of this discovery corroborate both the role of the CIV mechanism in the accretion of solid bodies from dusty plasma as well as the observation of SSs in the interstellar plasma medium.”[22]

Theory development

Typical Critical Ionization Velocities
(After Alfvén (1976))
Element lonization potential
Vion (V)
atomic mass
Critical Velocity
Vcrit (105 cm/sec)
(= km/sec)
Hydrogen 13.5 1.0 50.9
Helium 24.5 4.0 34.3
Neon 21.5 20.2 14.3
Nitrogen 14.5 14.0 14.1
Carbon 11.2 12.0 13.4
Oxygen 13.5 16.0 12.7

Mathematically, the critical ionization velocity of a neutral cloud, that is, when the cloud begins to become ionized, is when the relative kinetic energy is equal to the ionization energy, that is:

\(\frac{1}{2} mv^2 = eV_{ion}\)

where eVion is the ionization potential of the atoms or molecules in the gas cloud, m is the mass, v is the velocity.

Alfvén considered a neutral gas cloud entering the Solar System, and noted that a neutral atom will fall towards the Sun under the influence of gravity, and its kinetic energy will increase. If their motion is random, collisions will cause the gas temperature to rise, so that at a certain distance from the Sun, the gas will ionize. Alfvén writes that the ionization potential of the gas, Vion, occurs when:

\(eV_{ion} = E_g = \frac{k M m}{r}\)

that is, at a distance of:

\(r_{i} = E_g = \frac{k M m}{eV_{ion}} = 6.9\cdot 10^{-20}M \frac{m’}{V_{ion}} = 13.5\cdot 10^{13} \frac{m’}{V_{ion}} cm\)

(where ri is the ion distance from the Sun of mass M, m’ is the atom weight, Vion is in volts, k is the gravitational constant). Then when the gas becomes ionized, electromagnetic forces come into effect, of which the most important is the magnetic force which is usually greater than the gravitatioal force which gives rise to a magnetic repulsion from the Sun. In other words, a neutral gas falling from infinity toward the Sun is stopped at a distance ri where it will accumulate, and perhaps condense into planets.

Alfvén found that by taking a gas cloud with an average ionisation voltage of 12V, and average atomic weight of 7, then the distance ri is found to coincide with the orbit of Jupiter.

The critical ionization velocity of hydrogen 50.9 x 105cm/s (50.9 km/s), and helium is 34.3 x 105cm/s (34.3 km/s), [23].

Alfvén concluded that the critical velocity Vcrit at which neutral gas atoms of mass ma, with an ionization potential of eVion, interacts strongly with a magnetized plasma is:

\(V_{crit} = V_{ion} = \left(\frac{2eV_{ion}}{m_a}\right)^{1/2}\)


Alfvén discusses his thoughts behind critical velocity, in his NASA publications Evolution of the Solar System, [24].. After criticising the “Inadequacy of the Homogeneous Disc Theory”, he writes:

“.. it is more attractive to turn to the alternative that the secondary bodies derive from matter falling in from “infinity” (a distance large compared to. the satellite orbit). This matter (after being stopped and given sufficient angular momentum) accumulates at specific distances from the central body. Such a process may take place when atoms or molecules in free fall reach a kinetic energy equal to their ionization energy. At this stage, the gas can become ionized by the process discussed in sec. 21.4; the ionized gas can then be stopped by the magnetic field of the central body and receive angular momentum by transfer from the central body as described in sec. 16.3.”.



Carl-Gunne Fälthammar writes:

On the basis of the experiments it has been possible to essentially clarify what happens (Raadu 1978)[25]: When the relative velocity between plasma and neutral gas reaches the critical velocity, an instability occurs which leads to strong electric field fluctuations, which transfers energy from the relative motion (between ions and neutral gas) to the electrons of the plasma. These can now in turn easily ionize the neutral gas particles. In order to trigger the instability it is sufficient that there exists the slightest ionization (e.g. as a result of cosmic radiation), which then grows like an avalanche. Certain problems remain, however, still to be solved (Brenning and Axnas 1988)[5].[26]



  1. Hannes Alfvén “On the cosmogony of the solar system”, in Stockholms Observatoriums Annaler (1942) Part I Part II Part III FULL TEXT
  2. Hannes Alfvén, On the Origin of the Solar System. Oxford: Clarendon Press, 1954 ACADEMIC BOOK
  3. Hannes Alfvén, Collision between a nonionized gas and a magnetized plasma, Rev. Mod. Phys., vol. 32, p. 710, 1960 PEER REVIEWED
  4. U.V. Fahleson, “Experiments with plasma moving through neutral gas”, Phys. Fluids, 4 123 (1961) PEER REVIEWED
  5. 5.0 5.1 Brenning, N ., Axnas, I: “Critical ionization velocity interactions : Some unsolved problemsFULL TEXT, (1988) Astrophys. Space Sci. 144 15 PEER REVIEWED
  6. R. Torbert,: “Review of ionospheric CIV experiments“, XXVIIth COSPAR Meet., (1988) Helsinki, Finland, paper XIII.2. 1
  7. Lai, Shu T., A review of critical ionization velocity] (2001) Reviews of Geophysics, Volume 39, Issue 4, p. 471-506 PEER REVIEWED
  8. G. Haerendel: “Plasma flow and critical velocity ionization in cometary comae“, (1986) Geophys. Res. Lett. 13 25 5 PEER REVIEWED
  9. Petelski, E. F.; Fahr, H. J.; Ripken, H. W.; Brenning, N.; Axnas, I., “Enhanced interaction of the solar wind and the interstellar neutral gas by virtue of a critical velocity effectFULL TEXT (1980) Astronomy and Astrophysics, vol. 87, no. 1-2, July 1980, p. 20-30 PEER REVIEWED
  10. U.V. Fahleson, “Experiments with plasma moving through neutral gas“, Phys. Fluids, 4 123 (1961) PEER REVIEWED
  11. Carl-Gunne Falthammar, Space Physics,FULL TEXT PDF section 6.4. The Critical Velocity, p.135. 2nd Ed. 2001
  12. Freeman, J. W., Jr.; Hills, H. K.; Fenner, M. A., “Some results from the Apollo 12 Suprathermal Ion Detector“,FULL TEXT (1973) Proceedings of the Lunar Science Conference, vol. 2, p.2093
  13. Lars Danielsson, “Review of the Critical Velocity of Gas-Plasma Interaction. I: Experimental ObservationsFULL TEXT, Astrophysics and Space Science (1973) PEER REVIEWED
  14. Manka, R. H., et al, “Evidence for acceleration of lunar ions”, in Lunar Science III, C. Watkins, ed., (The Lunar Science Institute, Houston, Tx.): 504. (1972)
  15. Hannes Alfvén, “Mass Distribution and the Critical VelocityFULL TEXT, Evolution of the Solar System (1976)
  16. G. Haerendel: “Plasma flow and critical velocity ionization in cometary comae“, (1986) Geophys. Res. Lett. 13 25 5 PEER REVIEWED
  17. Golbraikh, E. I.; Filippov, M. A., Possible manifestation of the critical ionization velocity phenomenon in the solar corona (1992), ESA, Study of the Solar-Terrestrial System.
  18. Peratt, Anthony; Verschuur, Gerrit, The Critical Ionization Velocity Signature Manifested in Interstellar Neutral Hydrogen Emission Profile Structure, (1992), Bulletin of the American Astronomical Society, Vol. 34, p.766
  19. Lai, Shu T., A review of critical ionization velocity] (2001) Reviews of Geophysics, Volume 39, Issue 4, p. 471-506 PEER REVIEWED
  20. Konz, C.; Lesch, H.; Birk, G. T.; Wiechen, H., “The Critical Velocity Effect as a Cause for the Hα Emission from the Magellanic StreamFULL TEXT (2001) in The Astrophysical Journal, Volume 548, Issue 1, pp. 249-252 PEER REVIEWED
  21. Gerrit L. Verschuur, “On The Critical Ionization Velocity Effect In Interstellar Space And Possible Detection Of Related Continuum Emission” (2007) IEEE Transactions on Plasma Science, Volume: 35, Issue: 4, Part 1 (Aug 2007) PEER REVIEWED (see also arXiv:0704.3021) FULL TEXT
  22. Rantsev-Kartinov, V. A., “Skeletal Structures in the Images of Cosmic Dust Clouds and Solar System Planets” (2007) IEEE Transactions on Plasma Science, Volume: 35, Issue: 4, Part 1 PEER REVIEWED
  23. Hannes Alfvén, Evolution of the Solar System (1980) “21. Mass Distribution And The Critical VelocityFULL TEXT
  24. Hannes Alfvén, Evolution of the Solar System (1980) “21. Mass Distribution And The Critical VelocityFULL TEXT
  25. Raadu, M. A., “The role of electrostatic instabilities in the critical ionization velocity mechanismFULL TEXT, Astrophysics and Space Science, vol. 55, no. 1, May 1978, p. 125-138.PEER REVIEWED
  26. Carl-Gunne Falthammar, “Space Physics”, 2nd edition, Stockholm August 2001, p.135 (Full text “Fälthammar compendium“)


Other references

  • Brenning, N .
